CS 457/557 -- Winter Quarter 2017

Project #4

Displacement Mapping, Bump Mapping, and Lighting

100 Points

Due: February 20


This page was last updated: February 17, 2017


Requirements:

The goals of this project are to use displacement mapping to turn a simple shape into a more interesting one, re-compute its normals, bump-map it, and light it.

The turnin for this project will be all of the source files and a PDF report containing:

This needs to be a PDF file turned into Teach with your other files. Be sure to keep your PDF outside your .zip file so I can gather up all the PDF files at once with a script.

Decaying Cosine

This shape is a decaying cosine wave like this:

The surface spreads across X and Y, rising in Z according to:
Z = A * cos(2πBr+C) * e-Dr
where:
r = x2 + y2

Getting the Normal:

Unlike RenderMan, GLSL has no calculatenormal( ) function to make displacement mapping go easier. So, you have to do it yourself. But, in this case, it's not too hard.

Remember that the cross product of two vectors gives you a third vector that is perpendicular to both. So, all you have to do to get the normal is determine 2 vectors that lie on the surface at the point in question (these are called tangent lines) and then take their cross product, and then normalize it.

Each tangent is determined by taking calculus derivatives:
float r = x*x + y*y;
float drdx = 2.*x;
float dzdx = -A*sin(2.*π*B*r+C) * 2.*π*B*drdx * exp(-D*r) + A*cos(2.*π*B*r+C) * exp(-D*r) * -D*drdx;

and
float drdy = 2.*y;
float dzdy = -A*sin(2.*π*B*r+C) * 2.*π*B*drdy * exp(-D*r) + A*cos(2.*π*B*r+C) * exp(-D*r) * -D*drdy;

The tangent vectors are then formed like this:
vec3 Tx = vec3(1., 0., dzdx )
and
vec3 Ty = vec3(0., 1., dzdy )

The normal is then formed like this:
vec3 normal = normalize( cross( Tx, Ty ) );

Lighting

Start with the lighting shader we looked at in class. Feel free to use it as-is or as a starting point, or feel free to make your own. At a minumim, you must be able to adjust Ka, Kd, Ks, shininess, and the light position.

Flow

Sample .glib File


##OpenGL GLIB

Perspective 70
LookAt 0 0 3  0 0 0  0 1 0

Vertex	  decaying.vert
Fragment  decaying.frag
Program   Decaying                                      \
                uA <-0.5 0.00 0.5>                      \
                uB <0.0 2.0 5.0>                        \
                uC <0.0 0.0 12.56>                      \
                uD <0. 0. 5.>                           \
                uNoiseAmp  <0.0 0. 5.>                  \
                uNoiseFreq <0.1 1. 5.>                  \
                uKa <0. 0.1 1.0>                        \
                uKd <0. 0.6 1.0>                        \
                uKs <0. 0.3 1.0>                        \
                uShininess <1. 10. 50.>                 \
                uLightX <-20. 5. 20.>                   \
                uLightY <-20. 10. 20.>                  \
                uLightZ <-20. 20. 20.>                  \
                uColor {1. .7 0. 1.}                    \
                uSpecularColor {1. 1. 1. 1.}


QuadXY  -0.2  1.  200 200


Note that you need to break the quad down into many sub-quads (the "200 200" above) so that there are enough vertices to create a smooth displacement function. Basically you are doing your own microfaceting.

Bump-Mapping

You've determined the normal. Now you want to perturb it in a seemingly random, yet coherent, way. Sounds like a job for noise, right?

Use the glman noise capability to get two noise values. These will be treated as an angle to rotate the normal about x and an angle to rotate the normal about y. Create at least two more sliders: uNoiseAmp and uNoiseFreq.

        vec4 nvx = texture( Noise3, uNoiseFreq*vMC );
	float angx = nvx.r + nvx.g + nvx.b + nvx.a  -  2.;
	angx *= uNoiseAmp;
        vec4 nvy = texture( Noise3, uNoiseFreq*vec3(vMC.xy,vMC.z+0.5) );
	float angy = nvy.r + nvy.g + nvy.b + nvy.a  -  2.;
	angy *= uNoiseAmp;

Rotate the normal like this:

vec3
RotateNormal( float angx, float angy, vec3 n )
{
        float cx = cos( angx );
        float sx = sin( angx );
        float cy = cos( angy );
        float sy = sin( angy );

        // rotate about x:
        float yp =  n.y*cx - n.z*sx;    // y'
        n.z      =  n.y*sx + n.z*cx;    // z'
        n.y      =  yp;
        // n.x      =  n.x;

        // rotate about y:
        float xp =  n.x*cy + n.z*sy;    // x'
        n.z      = -n.x*sy + n.z*cy;    // z'
        n.x      =  xp;
        // n.y      =  n.y;

        return normalize( n );
}

Grading:

FeaturePoints
Correctly show the effect of changing A20
Correctly show the effects of changing B and C20
Correctly show the effect of changing D20
Use lighting to show that you have computed the normal correctly20
Use lighting to show that you have computed the bump-mapping correctly20
Potential Total100
